Basic Info.
Product Description
2. Low Consumption: Standby State power less then 3w, saving energy.
3. Three light indicator,check the charging information at any time clearly.
| Model NO | JL-MB251 | JL-MB252 | JL-MB253 | ||
| Appearance Structure | Product type | Swipe card activation | |||
| Shell material | Gun head PC9330, pillar box ABS | ||||
| Size | Gun head 230*98*58mm/ Pillar box 300*220*80mm(H*W*D) | ||||
| Installation type | Pillars standing/wall mounted | ||||
| Install components | Wall mounted screw accessories/ reraining washer (can be installed with pillars) | ||||
| Wiring method | Down in and down out | ||||
| Weight | 3. 7K G | 4. 5K G | |||
| Cable specification | 3*6mm²+0. 75mm² | 8 A W G x 2 C + 1 0 A W G + 1 8 A W G | |||
| Cable length | 5 meters(Customization) | ||||
| Electrical Specifications | Input voltage | A C 2 4 0 V | |||
| Input Frequency | 50Hz /60Hz | ||||
| Max power | 7 . 6 K W | 9 . 6 K W | 1 1 . 5 K W | ||
| Output voltage | A C 2 4 0 V | ||||
| Output current | 3 2 A | 4 0 A | 4 8 A | ||
| Stand-by power | 3W | ||||
| Environment Pointer | Applicable scenarios | Indoor/Outdoor | |||
| Relative humidity | 5%~95% | ||||
| Working temperature | -30ºC~+50ºC | ||||
| Working altitude | <2000 meters | ||||
| Protection class | Gun head IP67/Control box IP54 | ||||
| Cooling mode | Natural Convection cooling | ||||
| Safety standard | SAEJ1772 | ||||
| Flameretardant grade | UL94 V0 | ||||
| Product Certification | UL,FCC | ||||
| Functional Design | Human Interface | LED indicator light | |||
| Communication Interface | / | ||||
| Package Specification | Box size/weight | L * W * H : 4 1 0 * 4 1 0 * 1 2 5 mm(4 . 5 KG) | L * W * H : 4 1 0 * 4 1 0 * 1 2 5 m m (5 . 3 KG) | ||
| Safety Design | Undervoltage protection,Overvoltage protection,Overload protection,Overcurrent protection,Over temperature protection,Leakage protection,Grounding protection,Lightning protection,Electrostatic protection,Flame retardant protection | ||||
